| PartZenbakia | S290AJ1-LE2 Rev.C2 |
| Marka | Innolux |
| Tamaina | 28.6 |
| Aplikazio | Digital Signage Stre |
| Ebazpena | 1920×540 |
| Konposizioa | LCM, a-Si TFT-LCD |
| Distira | |
| CR | 4500:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| fabrikatzailea | Innolux |
| ereduaren izena | S290AJ1-LE2 Rev.C2 |
| pantailaren tamaina | 28.6 inch (1/2 cut of 32.0") |
| pantaila mota | LCM, a-Si TFT-LCD |
| pixel-zenbakia | 1920(RGB)×540 69PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 698.4 × 196.425 (H×V) |
| eskema (mm) | 720.8 × 226.3 × 26.8 (H×V×D) |
| bezela eremua (mm) | 702.4 × 200.4 (H×V) |
| tratamendua | Antiglare (Haze 2.4%), Hard coating (3H) |
| luminantzia | 1000 cd/m² (Typ.) |
| kontraste-erlazioa | 4500 : 1 (Typ.) (TM) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10) |
| erantzuna | 9.5 (Typ.)(G to G) ms |
| ikuspegi ona | Symmetry |
| lan egiteko modua | Super MVA, Normally Black, Transmissive |
| kolore-sakonera | 16.7M 72% NTSC |
| atzeko argia | WLED , 50K hours , With LED Driver |
| masa | 2.40/2.59/2.80Kgs (Min./Typ./Max.) |
| erabiltzen | Digital Signage Stretched Bar LCD |
| freskatze tasa | 60Hz |
| pantaila taktila | Without |
| seinale mota | LVDS (2 ch, 8-bit) , Connector 51 pins |
| tentsio-hornidura | 12.0V (Typ.) |
| gehienez. balorazioak | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
