| PartZenbakia | S032Q10 |
| Marka | CDTECH |
| Tamaina | 3.2 |
| Aplikazio | Handheld & PDA |
| Ebazpena | 240×320 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 350:1 |
| Koloreak | 262K |
| Atzeko argia | 1S5P |
| Interfazea | CPU |
| panel marka | CDTECH |
| panel eredua | S032Q10 |
| panelaren tamaina | 3.2" |
| panel mota | a-Si TFT-LCD, LCM |
| ebazpena | 240(RGB)×320, QVGA, 127PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 47.88(W)×63.84(H) mm |
| bezela irekidura | - |
| eskema tamaina | 55.04(W)×77.7(H) ×2.5(D) mm |
| azalera | - |
| distira | 270 cd/m² (Typ.) |
| kontraste-erlazioa | 350:1 (Typ.) (TM) |
| ikuspegi angelua | 55/65/65/65 (Typ.)(CR≥10) |
| bistaratzeko modua | TN, Normally White, Transmissive |
| ikuspegirik onena | 9 o'clock |
| erantzun denbora | 20 (Typ.)(Tr+Td) |
| bistaratzeko koloreak | 262K |
| lanpara mota | 1S5P WLED , 25K hours , Without Driver |
| maiztasuna | - |
| pantaila taktila | Without |
| panelaren pisua | TBD |
| aplikazio | Handheld & PDA |
| seinale interfazea | CPU , 37 pins FPC |
| sarrerako tentsioa | 3.3/3.3V (Max.)(VCC/IOVCC) |
| ingurunea | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
