| PartZenbakia | S029Q03 |
| Marka | CDTECH |
| Tamaina | 2.9 |
| Aplikazio | Stretched Bar LCD |
| Ebazpena | 320×120 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 400:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | 8/9/16/18-bit |
| marka | CDTECH |
| eredua | S029Q03 |
| diagonalaren tamaina | 2.9 inch (1/2 cut of 3.5") |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 320(RGB)×120 115PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 70.08(H)×26.284(V) mm |
| eskema dim. | 76.9(H)×37.72(V) ×3.46(D) mm |
| bezela eremua | 72.68(H)×28.88(V) mm |
| tratamendua | - |
| luminantzia | 300 cd/m² (Typ.) |
| kontraste-erlazioa | 400:1 (Typ.) (TM) |
| ikusi norabidea | 12 o'clock |
| erantzun denbora | 8/17 (Typ.)(Tr/Td) |
| ikuspegi angelua | 65/65/55/65 (Typ.)(CR≥10) |
| funtzionamendu modua | TN, Normally White, Transmissive |
| euskarria kolorea | 262K 61% NTSC |
| argi iturria | WLED [6S1P] , 30K hours , W/O Driver |
| pisua | TBD |
| entzat diseinatua | Stretched Bar LCD |
| fotograma-tasa | - |
| ukipen-panela | Without |
| interfaze mota | 8/9/16/18-bit 6800/8080 parallel, 6/9/16/18-bit RGB, SPI , 54 pins FPC |
| energia hornidura | 3.3/3.3V (Typ.)(VCI/VDDIO) |
| ingurunea | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
