| PartZenbakia | R156B48-167-0101 |
| Marka | No Brand |
| Tamaina | 15.6 |
| Aplikazio | Laptop |
| Ebazpena | 1366×768 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 500:1 |
| Koloreak | 262K |
| Atzeko argia | 8S6P |
| Interfazea | LVDS |
| panel marka | No Brand |
| panel eredua | R156B48-167-0101 1 Compatible |
| panelaren tamaina | 15.6" |
| panel mota | a-Si TFT-LCD, LCM |
| ebazpena | 1366(RGB)×768, WXGA, 100PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 344.232(W)×193.536(H) mm |
| bezela irekidura | - |
| eskema tamaina | 359.3(W)×209.5(H) ×5.5(D) mm |
| azalera | Glare (Haze 0%) |
| distira | 200 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) (TM) |
| ikuspegi angelua | 45/45/20/40 (Typ.)(CR≥10) |
| bistaratzeko modua | TN, Normally White, Transmissive |
| ikuspegirik onena | - |
| erantzun denbora | 12 (Typ.)(Tr+Td) |
| bistaratzeko koloreak | 262K 45% NTSC |
| lanpara mota | 8S6P WLED , 15K hours , With LED Driver |
| maiztasuna | 60Hz |
| pantaila taktila | Without |
| forma estiloa | Wedge (PCBA Bent, T≥5.2mm) |
| aplikazio | Laptop |
| seinale interfazea | LVDS (1 ch, 6-bit) , 40 pins Connector |
| sarrerako tentsioa | 3.3V (Typ.) |
| ingurunea | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| B156HTN04.0 | AUO | 15.6 | 1920×1080 |
| BT156GW01 V.4 | Innolux | 15.6 | 1366×768 |
| LTN156AT01-B01 | Samsung | 15.6 | 1366×768 |
| LTN156AT01-B02 | Samsung | 15.6 | 1366×768 |
| LTN156AT05-H01 | Samsung | 15.6 | 1366×768 |
| LTN156AT17-D01 | Samsung | 15.6 | 1366×768 |
| N156B3-L02 | Innolux | 15.6 | 1366×768 |
| N156BGE-E42 | Innolux | 15.6 | 1366×768 |
| N156O6-L02 | Innolux | 15.6 | 1600×900 |
| TMS156WX1-02TC | Tianma | 15.6 | 1366×768 |
