| PartZenbakia | QD14FL02 Rev.01 |
| Marka | QDI |
| Tamaina | 14.1 |
| Aplikazio | NBPC |
| Ebazpena | 1400×1050 |
| Konposizioa | LCM |
| Distira | 175 |
| CR | 300:1 |
| Koloreak | 262K |
| Atzeko argia | CCFL |
| Interfazea | LVDS |
| panel marka | QDI |
| panel eredua | QD14FL02 Rev.01 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 14.1 inch |
| ebazpena | 1400(RGB)×1050 , SXGA+ |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 285.7×214.3 mm |
| eskema | 299×240.6×5.5 mm |
| forma estiloa | Wedge (PCBA Bent, Depth ≥5.2mm) |
| azalera | Antiglare, Hard coating (3H) |
| distira | 175 cd/m² (Typ.) |
| kontraste-erlazioa | 300:1 (Min.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193150% |
| erantzun denbora | 10/15 (Typ.)(Tr/Td) |
| ikuspegi angelua | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 1 pcsCCFLEmbedded (Inverter) |
| seinale interfazea | LVDS (2 ch, 6-bit), 30 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| rohs: | |
| aplikazio | NBPC |
