| PartZenbakia | PT236AT02-1 |
| Marka | HKC |
| Tamaina | 23.6 |
| Aplikazio | TV Sets |
| Ebazpena | 1366×768 |
| Konposizioa | a-Si TFT-LCD , CELL |
| Distira | |
| CR | 3000:1 |
| Koloreak | 16.7M |
| Atzeko argia | No |
| Interfazea | LVDS |
| panel marka | HKC |
| panelaren tamaina | 23.6" |
| ebazpena | 1366(RGB)×768, WXGA, 66PPI |
| bistaratzeko eremua | 521.471(W)×293.184(H) mm |
| eskema tamaina | 535.471(W)×306.404(H) ×1.37(D) mm |
| distira | 0 cd/m² |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10) |
| ikuspegirik onena | Symmetry |
| beiraren sakonera | 0.50+0.50 mm |
| bistaratzeko koloreak | 16.7M 71% NTSC |
| maiztasuna | 60Hz |
| gidariaren ic | COF Built-in 2 source + 2 gate chips |
| panelaren pisua | 500g (Typ.) |
| seinale interfazea | LVDS (1 ch, 8-bit) , 30 pins Connector |
| sarrerako tentsioa | 12.0V (Typ.) |
| ingurunea | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| panel eredua | PT236AT02-1 |
| panel mota | a-Si TFT-LCD , CELL |
| pixel formatua | RGB Vertical Stripe |
| bezela irekidura | - |
| azalera | Antiglare (Haze 3%), Hard coating (3H) |
| kontraste-erlazioa | 3000:1 (Typ.) (TM) |
| bistaratzeko modua | FSA, Normally Black, Transmissive |
| erantzun denbora | 9.5 (Typ.)(G to G) |
| transmisibitatea | 5.8% (Typ.)(with Polarizer) |
| lanpara mota | No B/L |
| pantaila taktila | Without |
| aplikazio | TV Sets |
