| PartZenbakia | PT156WHM-N10 |
| Marka | BOE |
| Tamaina | 15.6 |
| Aplikazio | Industrial |
| Ebazpena | 1366×768 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 500:1 |
| Koloreak | 262K |
| Atzeko argia | 10S4P |
| Interfazea | |
| panel marka | BOE |
| panelaren tamaina | 15.6" |
| ebazpena | 1366(RGB)×768, WXGA, 100PPI |
| bistaratzeko eremua | 344.23(W)×193.54(H) mm |
| eskema tamaina | 359.5(W)×223.8(H) ×3.2(D) mm |
| distira | 400 cd/m² (Typ.) |
| ikuspegi angelua | 45/45/20/40 (Typ.)(CR≥10) |
| ikuspegirik onena | - |
| bistaratzeko koloreak | 262K 45% NTSC |
| maiztasuna | 60Hz |
| pisua | 370g (Max.) |
| panel eredua | PT156WHM-N10 (BOE06A5) |
| panel mota | a-Si TFT-LCD , LCM |
| pixel formatua | RGB Vertical Stripe |
| bezela irekidura | - |
| azalera | Antiglare |
| kontraste-erlazioa | 500:1 (Typ.) (TM) |
| bistaratzeko modua | TN, Normally White, Transmissive |
| erantzun denbora | 12 (Typ.)(Tr+Td) |
| lanpara mota | 10S4P WLED , 30K hours , With LED Driver |
| pantaila taktila | Without |
| aplikazio | Industrial |
| B156XW02 V0 | AUO | 15.6 | 1366×768 |
| B156XW04 V0 | AUO | 15.6 | 1366×768 |
| LM156WH1-TLE1 | LG Display | 15.6 | 1366×768 |
| LP156WD1-TLD5 | LG Display | 15.6 | 1600×900 |
| LTN156AT01-B02 | Samsung | 15.6 | 1366×768 |
| LTN156AT02-A11 | Samsung | 15.6 | 1366×768 |
| LTN156HT01-201 | Samsung | 15.6 | 1920×1080 |
| M156B1-L01 | Innolux | 15.6 | 1366×768 |
| N156B6-L0A | Innolux | 15.6 | 1366×768 |
| N156BGE-L31 | Innolux | 15.6 | 1366×768 |
