| PartZenbakia | P546HW01 V0 |
| Marka | AUO |
| Tamaina | 55 |
| Aplikazio | PID |
| Ebazpena | 1920×1080 |
| Konposizioa | LCM |
| Distira | 500 |
| CR | 5000:1 |
| Koloreak | 1.07B |
| Atzeko argia | CCFL |
| Interfazea | LVDS |
| panel marka | AUO |
| panel eredua | P546HW01 V0 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 55 inch |
| ebazpena | 1920(RGB)×1080 , FHD |
| bistaratzeko modua | AMVA3, Normally Black, Transmissive |
| eremu aktiboa | 1209.6×680.4 mm |
| eskema | 1286×745 mm |
| azalera | Antiglare, Hard coating (3H) |
| distira | 500 cd/m² (Typ.) |
| kontraste-erlazioa | 5000:1 (Typ.) |
| bistaratzeko koloreak | 1.07B (8-bit + Hi-FRC), CIE193172% |
| erantzun denbora | 15/8 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | CCFLEmbedded (Inverter) |
| seinale interfazea | LVDS (2 ch, 10-bit), 51 pins |
| sarrerako tentsioa | 12.0V (Typ.) |
| aplikazio | PID |
| LC550DUJ-SGE1 | LG Display | 55 | 1920×1080 |
| LC550EUD-SEF3 | LG Display | 55 | 1920×1080 |
| LC550EUF-PGF1 | LG Display | 55 | 1920×1080 |
| LC550EUG-KEF1 | LG Display | 55 | 1920×1080 |
| LC550EUN-PFF1 | LG Display | 55 | 1920×1080 |
| LD550DUN-THB3 | LG Display | 55 | 1920×1080 |
| LTF550HF01 | Samsung | 55 | 1920×1080 |
| P546HW01 V0 | AUO | 55 | 1920×1080 |
| P546HW03 V0 | AUO | 55 | 1920×1080 |
| V546HK3-LS5 Rev.C7 | Innolux | 55 | 1920×1080 |
| LD420EUB-SDA1 | LG Display | 42 | 1920×1080 |
| LD840EQD-SEM1 | LG Display | 84 | 3840×2160 |
| LQ695D3LG04 | SHARP | 70 | 1920×1080 |
| LTI320AA02 | Samsung | 31.5 | 1366×768 |
| LTI400HA08-V | Samsung | 40 | 1920×1080 |
| LTI460HM02 | Samsung | 46 | 1920×1080 |
| LTI750HF01 | Samsung | 75 | 1920×1080 |
| LTI820HT-L01 | Samsung | 82 | 1920×1080 |
| P270HVN01.0 | AUO | 27.0 | 1920×1080 |
| P320HVN02.1 | AUO | 31.5 | 1920×1080 |
