| PartZenbakia | P101DCZ-3Z0 |
| Marka | Innolux |
| Tamaina | 10.1 |
| Aplikazio | Pad & Tablet |
| Ebazpena | 800×1280 |
| Konposizioa | CELL , a-Si TFT-LC |
| Distira | |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | No |
| Interfazea | MIPI |
| fabrikatzailea | Innolux |
| pantailaren tamaina | 10.1 inch |
| pixel-zenbakia | 800(RGB)×1280 (WXGA) 150PPI |
| eremu aktiboa (mm) | 135.36 × 216.576 (H×V) |
| bezela eremua (mm) | - |
| luminantzia | 0 cd/m² |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| ikuspegi ona | Symmetry |
| beira lodiera | - |
| kolore-sakonera | 16.7M 59% NTSC |
| masa | - |
| freskatze tasa | 60Hz |
| seinale mota | MIPI (4 data lanes) , 40 pins Connector |
| tentsio-hornidura | 3.3/5.8/-5.8V (Typ.)(VDDIN/AVDD/AVEE) |
| gehienez. balorazioak | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| ereduaren izena | P101DCZ-3Z0 |
| pantaila mota | CELL , a-Si TFT-LCD |
| antolamendua | RGB Vertical Stripe |
| eskema (mm) | - |
| tratamendua | Clear, Hard coating (3H) |
| kontraste-erlazioa | 800 : 1 (Typ.) (TM) |
| erantzuna | 25 (Typ.)(Tr+Td) ms |
| lan egiteko modua | AAS, Normally Black, Transmissive |
| transmisibitatea | 4.73% (Typ.)(with Polarizer) |
| atzeko argia | No B/L |
| erabiltzen | Pad & Tablet |
| pantaila taktila | Without |
