| PartZenbakia | NV116WHM-T04 |
| Marka | BOE |
| Tamaina | 11.6 |
| Aplikazio | Laptop |
| Ebazpena | 1366×768 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 1000:1 |
| Koloreak | 262K |
| Atzeko argia | 8S3P |
| Interfazea | eDP |
| panel marka | BOE |
| panel eredua | NV116WHM-T04 (BOE0965) |
| panelaren tamaina | 11.6" |
| panel mota | a-Si TFT-LCD, LCM |
| ebazpena | 1366(RGB)×768, WXGA, 135PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 256.125(W)×144(H) mm |
| bezela irekidura | - |
| eskema tamaina | 278(W)×168(H) ×3.2(D) mm |
| azalera | Glare (Haze 0%), Hard coating (3H) |
| distira | 250 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) (TM) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| bistaratzeko modua | ADS, Normally Black, Transmissive |
| ikuspegirik onena | Symmetry |
| erantzun denbora | 20 (Typ.)(Tr+Td) |
| bistaratzeko koloreak | 262K 50% NTSC |
| lanpara mota | 8S3P WLED , 15K hours , With LED Driver |
| maiztasuna | 60Hz |
| pantaila taktila | On-Cell Touch |
| forma estiloa | Slim (PCBA Flat, T≤3.2mm) |
| aplikazio | Laptop |
| seinale interfazea | eDP (1 Lane) , eDP1.2 , HBR1 (2.7G/lane) , 40 pins Connector |
| sarrerako tentsioa | 3.3V (Typ.) |
| ingurunea | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| B116HAN03.1 | AUO | 11.6 | 1920×1080 |
| B116XTN02.3 HW0A | AUO | 11.6 | 1366×768 |
| B116XW05 V004 | AUO | 11.6 | 1366×768 |
| LP116WH2-TLN1 | LG Display | 11.6 | 1366×768 |
| LP116WH4-SLN1 | LG Display | 11.6 | 1366×768 |
| LP116WH6-SLA1 | LG Display | 11.6 | 1366×768 |
| LTN116AT02-D01 | Samsung | 11.6 | 1366×768 |
| LTN116AT06-L02 | Samsung | 11.6 | 1366×768 |
| M116NWR1 R3 | IVO | 11.6 | 1366×768 |
| N116HSE-EA2 | Innolux | 11.6 | 1920×1080 |
