| PartZenbakia | NV101WUM-N52 |
| Marka | BOE |
| Tamaina | 10.1 |
| Aplikazio | Pad & Tablet |
| Ebazpena | 1200×1920 |
| Konposizioa | LCM , a-Si TFT-LCD |
| Distira | |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| fabrikatzailea | BOE |
| pantailaren tamaina | 10.1 inch |
| pixel-zenbakia | 1200(RGB)×1920 (WUXGA) 225PPI |
| eremu aktiboa (mm) | 135.36 × 216.576 (H×V) |
| luminantzia | 400 cd/m² (Typ.) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10) |
| ikuspegi ona | Symmetry |
| kolore-sakonera | 16.7M 68% NTSC |
| masa | 132g (Typ.) |
| freskatze tasa | 60Hz |
| seinale mota | MIPI (4 data lanes) , 42 pins Connector |
| tentsio-hornidura | 1.8/3.3V (Typ.)(VDD1/VDD3) |
| gehienez. balorazioak | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| ereduaren izena | NV101WUM-N52 |
| pantaila mota | LCM , a-Si TFT-LCD |
| antolamendua | RGB Vertical Stripe |
| eskema (mm) | 141.56 × 228.226 × 4.2 (H×V×D) |
| kontraste-erlazioa | 1000 : 1 (Typ.) (TM) |
| erantzuna | 35 (Max.)(Tr+Td) ms |
| lan egiteko modua | ADS, Normally Black, Transmissive |
| atzeko argia | WLED , 15K hours , No Driver |
| erabiltzen | Pad & Tablet |
| pantaila taktila | Without |
