PartZenbakia | NT133WHM-A10 |
Marka | BOE |
Tamaina | 13.3 |
Aplikazio | Laptop |
Ebazpena | 1366×768 |
Konposizioa | a-Si TFT-LCD , Assem |
Distira | |
CR | 600:1 |
Koloreak | 262K |
Atzeko argia | WLED |
Interfazea | eDP |
marka | BOE |
diagonalaren tamaina | 13.3 inch |
pixel formatua | 1366(RGB)×768 [WXGA] 118PPI |
eremu aktiboa | 293.42(H)×164.97(V) mm |
luminantzia | 220 cd/m² (Typ.) |
ikusi norabidea | 6 o'clock |
ikuspegi angelua | 80/80/80/80 (Min.)(CR≥10) |
euskarria kolorea | 262K 45% NTSC |
forma estiloa | Slim (PCBA Flat, T≤3.2mm) |
fotograma-tasa | 60Hz |
interfaze mota | eDP (1 Lane) , 30 pins Connector |
energia hornidura | 3.3V (Typ.) |
ingurunea | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
eredua | NT133WHM-A10 |
mota | a-Si TFT-LCD , Assembly |
konfigurazioa | RGB Vertical Stripe |
eskema dim. | - |
kontraste-erlazioa | 600:1 (Typ.) (TM) |
erantzun denbora | 30 (Typ.)(Tr+Td) |
funtzionamendu modua | - |
argi iturria | WLED [9S4P] , 15K hours , With LED Driver |
entzat diseinatua | Laptop |
ukipen-panela | Without |
