| PartZenbakia | NL12880BC20-25F |
| Marka | NLT |
| Tamaina | 12.1 |
| Aplikazio | Industrial Outdoor H |
| Ebazpena | 1280×800 |
| Konposizioa | LCM, a-Si TFT-LCD |
| Distira | |
| CR | 800:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | 3 |
| Interfazea | LVDS |
| fabrikatzailea | NLT |
| ereduaren izena | NL12880BC20-25F |
| pantailaren tamaina | 12.1 inch |
| pantaila mota | LCM, a-Si TFT-LCD |
| pixel-zenbakia | 1280(RGB)×800 (WXGA) 124PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 261.12 × 163.2 (H×V) |
| eskema (mm) | 277.7 × 180.6 × 9.2 (H×V×D) |
| bezela eremua (mm) | 266.1 × 168.2 (H×V) |
| tratamendua | Antiglare, Hard coating (3H) |
| luminantzia | 1600 cd/m² (Typ.) |
| kontraste-erlazioa | 800 : 1 (Typ.) (TM) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10) |
| erantzuna | 15 (Typ.)(Tr+Td) ms |
| ikuspegi ona | 6 o'clock |
| lan egiteko modua | TN, Normally White, Transmissive |
| kolore-sakonera | 262K/16.7M 50% NTSC |
| atzeko argia | 3 strings WLED , 60K hours , No Driver |
| masa | 470g (Typ.) |
| erabiltzen | Industrial Outdoor High Brightness |
| freskatze tasa | 60Hz |
| pantaila taktila | Without |
| seinale mota | LVDS (1 ch, 6/8-bit) , Connector 20 pins |
| tentsio-hornidura | 3.3V (Typ.) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.0G (19.6 m/s²) |
