| PartZenbakia | NE070NB-04F |
| Marka | Chimei Innolux |
| Tamaina | 7.0 |
| Aplikazio | Digital Photo Frame |
| Ebazpena | 800×480 |
| Konposizioa | a-Si TFT-LCD, CELL |
| Distira | |
| CR | 500:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | No |
| Interfazea | Parallel |
| marka | Chimei Innolux |
| eredua | NE070NB-04F |
| diagonalaren tamaina | 7.0 inch |
| mota | a-Si TFT-LCD, CELL |
| pixel formatua | 800(RGB)×480 [WVGA] 134PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 154.08(H)×85.92(V) mm |
| eskema dim. | 162.5(H)×96.62(V) ×1.43(D) mm |
| bezela eremua | - |
| tratamendua | Antiglare |
| luminantzia | 0 cd/m² |
| kontraste-erlazioa | 500:1 (Typ.) (TM) |
| ikusi norabidea | 6 o'clock |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 70/70/50/70 (Typ.)(CR≥10) |
| funtzionamendu modua | TN, Normally White, Transmissive |
| plakaren lodiera | 0.50+0.50 mm |
| transmisioa | 4.86% (Typ.)(with Polarizer) |
| euskarria kolorea | 262K/16.7M |
| argi iturria | No B/L |
| pisua | 45.0g (Typ.) |
| entzat diseinatua | Digital Photo Frame Portable DVD Player |
| fotograma-tasa | 60Hz |
| ukipen-panela | Without |
| d-ic xehetasuna | COG Built-in 1 source + 1 gate chips |
| interfaze mota | Parallel RGB (1 ch, 6/8-bit) , 50 pins FPC |
| energia hornidura | 3.3/10.4/15/-10V (Typ.)(DVDD/AVDD/VGH/VGL) |
| ingurunea | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
