| PartZenbakia | ND168TXP01 |
| Marka | |
| Tamaina | 16.8 |
| Aplikazio | PID |
| Ebazpena | 1366×378 |
| Konposizioa | LCM |
| Distira | 800 |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | |
| panel eredua | ND168TXP01 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 16.8 inch(1/2 cut of 18.5") |
| ebazpena | 1366(RGB)×378 |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 409.8×113.4 mm |
| eskema | 430.37×137.3×11.5 mm |
| azalera | Antiglare, Hard coating (3H) |
| distira | 800 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (6-bit + Hi-FRC), CIE193171% |
| erantzun denbora | 5 (Typ.)(Tr+Td) |
| ikuspegi angelua | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | WLEDEmbedded (LED Driver) |
| seinale interfazea | LVDS (1 ch, 8-bit), 30 pins |
| sarrerako tentsioa | 5.0V (Typ.) |
| aplikazio | PID |
