| PartZenbakia | N154Z1-L01 |
| Marka | Innolux |
| Tamaina | 15.4 |
| Aplikazio | NBPC |
| Ebazpena | 1680×1050 |
| Konposizioa | LCM |
| Distira | 200 |
| CR | 500:1 |
| Koloreak | 262K |
| Atzeko argia | CCFL |
| Interfazea | LVDS |
| panel marka | CMO |
| panel eredua | N154Z1-L01 9 Compatible model |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 15.4 inch |
| ebazpena | 1680(RGB)×1050 , WSXGA+ |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 331.128×206.955 mm |
| eskema | 344×222×6.5 mm |
| forma estiloa | Wedge (PCBA Bent, Depth ≥5.2mm) |
| azalera | Antiglare, Hard coating (2H) |
| distira | 200 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193145% |
| erantzun denbora | 4/12 (Typ.)(Tr/Td) |
| ikuspegi angelua | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 1 pcsCCFLWithout Driver |
| seinale interfazea | LVDS (2 ch, 6-bit), 30 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | NBPC |
| B154EW02 V1 | AUO | 15.4 | 1280×800 |
| LP154WX4-TLC5 | LG Display | 15.4 | 1280×800 |
| LTN154AT07-H01 | Samsung | 15.4 | 1280×800 |
| LTN154AT07-L01 | Samsung | 15.4 | 1280×800 |
| LTN154P1-L03 | Samsung | 15.4 | 1680×1050 |
| N154C6-L04 | Innolux | 15.4 | 1440×900 |
| N154I6-L03 | Innolux | 15.4 | 1280×800 |
| N154Z1-L01 | Innolux | 15.4 | 1680×1050 |
| N154Z1-L02 | Innolux | 15.4 | 1680×1050 |
| N154Z3-L01 | Innolux | 15.4 | 1680×1050 |
| B141XN04 V2 | AUO | 14.1 | 1024×768 |
| LP125WH2-SLB2 | LG Display | 12.5 | 1366×768 |
| LP140WD1-TLM1 | LG Display | 14.0 | 1600×900 |
| LP140WH2-TLB1 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TPS1 | LG Display | 14.0 | 1366×768 |
| LP154WU1-A1K3 | LG Display | 15.4 | 1920×1200 |
| LP171WU6-TLA2 | LG Display | 17.1 | 1920×1200 |
| LTD121EXSS | TOSHIBA | 12.1 | 1280×800 |
| LTN141AT16-003 | Samsung | 14.1 | 1280×800 |
| LTN154X3-L03 | Samsung | 15.4 | 1280×800 |
