| PartZenbakia | M236H3-L05 |
| Marka | Innolux |
| Tamaina | 23.6 |
| Aplikazio | DMPC |
| Ebazpena | 1920×1080 |
| Konposizioa | LCM |
| Distira | 300 |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | CHIMEI INNOLUX |
| panel eredua | M236H3-L05 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 23.6 inch |
| ebazpena | 1920(RGB)×1080 , FHD |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 521.28×293.22 mm |
| eskema | 544.8×320.5 mm |
| azalera | Antiglare (Haze 25%), Hard coating (3H) |
| distira | 300 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit) |
| erantzun denbora | 1.5/3.5 (Typ.)(Tr/Td) |
| ikuspegi angelua | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 120Hz |
| lanpara mota | 12S6PWLEDWithout Driver |
| seinale interfazea | LVDS (4 ch, 8-bit), 66 pins |
| sarrerako tentsioa | 5.0V (Typ.) |
| aplikazio | DMPC |
