| PartZenbakia | M170ETN01.0 |
| Marka | AUO |
| Tamaina | 17.0 |
| Aplikazio | DMPC |
| Ebazpena | 1280×1024 |
| Konposizioa | LCM |
| Distira | 250 |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | CCFL |
| Interfazea | LVDS |
| panel marka | AUO |
| panel eredua | M170ETN01.0 3 Compatible model |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 17.0 inch |
| ebazpena | 1280(RGB)×1024 , SXGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 337.92×270.336 mm |
| eskema | 358.5×296.5×15.8 mm |
| azalera | Antiglare, Hard coating (3H) |
| distira | 250 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (6-bit + Hi-FRC) |
| erantzun denbora | 3.5/1.5 (Typ.)(Tr/Td) |
| ikuspegi angelua | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 2 pcsCCFLWithout Driver |
| seinale interfazea | LVDS (2 ch, 8-bit), 30 pins |
| sarrerako tentsioa | 5.0V (Typ.) |
| aplikazio | DMPC |
| M170E5-L0A | Innolux | 17.0 | 1280×1024 |
| M170EG01 V0 | AUO | 17.0 | 1280×1024 |
| M170EG01 V5 | AUO | 17.0 | 1280×1024 |
| M170EG01 V8 | AUO | 17.0 | 1280×1024 |
| M170EG01 V9 | AUO | 17.0 | 1280×1024 |
| M170EG01 VH | AUO | 17.0 | 1280×1024 |
| M170EGE-L20 | Innolux | 17.0 | 1280×1024 |
| M170EN04 V6 | AUO | 17.0 | 1280×1024 |
| M170ETN01.0 | AUO | 17.0 | 1280×1024 |
| M170EU01 V0 | AUO | 17.0 | 1280×1024 |
| LM185WH1-TLA1 | LG Display | 18.5 | 1366×768 |
| LM215DT8A | PANDA | 21.5 | 1920×1080 |
| LM230WF5-TLD5 | LG Display | 23.0 | 1920×1080 |
| LTM170EU-A01 | Samsung | 17.0 | 1280×1024 |
| LTM215HL01 | Samsung | 21.5 | 1920×1080 |
| LTM300M1-P02 | Samsung | 30.0 | 2560×1600 |
| M236H3-LA2 | Innolux | 23.6 | 1920×1080 |
| M240J1-L03 | Innolux | 24.0 | 1920×1200 |
| MV190E0M-N10 | BOE | 19.0 | 1280×1024 |
| TD170WGCA1 | TPO | 17.0 | 1280×1024 |
