| PartZenbakia | M102AWF2 R3 |
| Marka | IVO |
| Tamaina | 10.3 |
| Aplikazio | Automotive Display |
| Ebazpena | 1920×720 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| marka | IVO |
| eredua | M102AWF2 R3 |
| diagonalaren tamaina | 10.3 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 1920(RGB)×720 200PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 243.65(H)×91.37(V) mm |
| eskema dim. | 261.14(H)×109.3(V) ×15.8(D) mm |
| bezela eremua | 245.65(H)×94.37(V) mm |
| tratamendua | Hard coating (3H) |
| luminantzia | 800 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) (TM) |
| ikusi norabidea | Symmetry |
| erantzun denbora | 20 (Typ.)(Tr+Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| funtzionamendu modua | IPS, Normally Black, Transmissive |
| euskarria kolorea | 16.7M 75% NTSC |
| argi iturria | WLED [8S3P] , 10K hours , W/O Driver |
| pisua | 350g (Max.) |
| entzat diseinatua | Automotive Display |
| fotograma-tasa | 55Hz |
| ukipen-panela | Without |
| interfaze mota | LVDS (2 ch, 8-bit) , 50 pins Connector |
| energia hornidura | 3.3V (Typ.) |
| ingurunea | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 3.0G (29.4 m/s²) |
