| PartZenbakia | LSM315DP01-M01 |
| Marka | SAMSUNG |
| Tamaina | 32.0 |
| Aplikazio | Desktop Monitor Gami |
| Ebazpena | 2560×1440 |
| Konposizioa | a-Si TFT-LCD , CELL |
| Distira | |
| CR | 3000:1 |
| Koloreak | 16.7M |
| Atzeko argia | No |
| Interfazea | eDP |
| marka | SAMSUNG |
| diagonalaren tamaina | 32.0 inch |
| pixel formatua | 2560(RGB)×1440 [Quad-HD] 93PPI |
| eremu aktiboa | 697.344(H)×392.256(V) mm |
| bezela eremua | - |
| luminantzia | 0 cd/m² |
| ikusi norabidea | Symmetry |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10) |
| plakaren lodiera | 0.40+0.40 mm |
| euskarria kolorea | 16.7M 70% NTSC |
| pisua | 900g (Typ.) |
| fotograma-tasa | 144Hz |
| d-ic xehetasuna | COF Built-in 8 source chips |
| interfaze mota | eDP (4 Lanes) , HBR2 (5.4G/lane) , 51 pins Connector |
| energia hornidura | 12.0V (Typ.) |
| ingurunea | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| eredua | LSM315DP01-M01 |
| mota | a-Si TFT-LCD , CELL |
| konfigurazioa | RGB Vertical Stripe |
| eskema dim. | 708.944(H)×405.731(V) ×1.11(D) mm |
| tratamendua | Antiglare (Haze 25%) |
| kontraste-erlazioa | 3000:1 (Typ.) (TM) |
| erantzun denbora | 22 (Typ.)(G to G) |
| funtzionamendu modua | PVA, Normally Black, Transmissive |
| transmisioa | 3.0% (Typ.)(with Polarizer) |
| argi iturria | No B/L |
| entzat diseinatua | Desktop Monitor Gaming |
| ukipen-panela | Without |
