| PartZenbakia | LS055R3SX01 |
| Marka | Sharp |
| Tamaina | 5.5 |
| Aplikazio | Mobile Phone |
| Ebazpena | 1536×2560 |
| Konposizioa | CG-Silicon , LCM |
| Distira | |
| CR | 1280:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| marka | Sharp |
| diagonalaren tamaina | 5.5 inch |
| pixel formatua | 1536(RGB)×2560 546PPI |
| eremu aktiboa | 71.424(H)×119.04(V) mm |
| luminantzia | 460 cd/m² (Typ.) |
| ikusi norabidea | Symmetry |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10) |
| euskarria kolorea | 16.7M 70% NTSC |
| pisua | 21.1g |
| fotograma-tasa | 60Hz |
| interfaze mota | MIPI (4 data lanes) , 32 pins Connector |
| energia hornidura | 1.8/5.5/-5.5V (Typ.)(IOVDD/VSP/VSN) |
| ingurunea | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| eredua | LS055R3SX01 |
| mota | CG-Silicon , LCM |
| konfigurazioa | RGB Vertical Stripe |
| eskema dim. | 73.824(H)×126.44(V) ×1.4(D) mm |
| kontraste-erlazioa | 1280:1 (Typ.) (TM) |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| funtzionamendu modua | New Mode2, Normally Black, Transmissive |
| argi iturria | WLED [8S2P] , W/O Driver |
| entzat diseinatua | Mobile Phone |
| ukipen-panela | Without |
