| PartZenbakia | LQ800D3HA01 |
| Marka | Sharp |
| Tamaina | 80 |
| Aplikazio | TV Sets |
| Ebazpena | 1920×1080 |
| Konposizioa | a-Si TFT-LCD, CELL |
| Distira | |
| CR | 5000:1 |
| Koloreak | 1.07B |
| Atzeko argia | No |
| Interfazea | LVDS |
| panel marka | Sharp |
| panel eredua | LQ800D3HA01 |
| panelaren tamaina | 80" |
| panel mota | a-Si TFT-LCD, CELL |
| ebazpena | 1920(RGB)×1080, FHD, 27PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 1771.2(W)×996.3(H) mm |
| bezela irekidura | - |
| eskema tamaina | 1802.6(W)×1026.9(H) ×1.7(D) mm |
| azalera | Antiglare (Haze 3%), Hard coating (2H) |
| distira | 0 cd/m² |
| kontraste-erlazioa | 5000:1 (Typ.) (TM) |
| ikuspegi angelua | 88/88/88/88 (Typ.)(CR≥10) |
| bistaratzeko modua | ASV, Normally Black, Transmissive |
| ikuspegirik onena | Symmetry |
| erantzun denbora | 4 (Typ.)(G to G) |
| beiraren sakonera | - |
| transmisibitatea | 6.51% (Typ.)(with Polarizer) |
| bistaratzeko koloreak | 1.07B 73% NTSC |
| lanpara mota | No B/L |
| maiztasuna | 120Hz |
| pantaila taktila | Without |
| gidariaren ic | COF Built-in 16 source + 10 gate chips |
| panelaren pisua | 7.80g (Typ.) |
| aplikazio | TV Sets |
| seinale interfazea | LVDS (4 ch, 10-bit) , 92 pins Connector |
| sarrerako tentsioa | 12.0V (Typ.) |
| ingurunea | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C |
