| PartZenbakia | LQ042Q1DW40P |
| Marka | Sharp |
| Tamaina | 4.2 |
| Aplikazio | Portable Navigation |
| Ebazpena | 320×320 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | Parallel |
| marka | Sharp |
| eredua | LQ042Q1DW40P |
| diagonalaren tamaina | 4.2 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 320(RGB)×320 [QVGA] 108PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 84.96(H)×63.72(V) mm |
| eskema dim. | 96.8(H)×71.5(V) mm |
| bezela eremua | - |
| tratamendua | Antiglare, Hard coating (3H) |
| luminantzia | 180 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) (TM) |
| ikusi norabidea | - |
| erantzun denbora | 35/35 (Typ.)(Tr/Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10) |
| funtzionamendu modua | TN, Normally White, Transmissive |
| euskarria kolorea | 16.7M |
| argi iturria | WLED [6S1P] , W/O Driver |
| pisua | 39.0g (Typ.) |
| entzat diseinatua | Portable Navigation |
| fotograma-tasa | 60Hz |
| ukipen-panela | Without |
| interfaze mota | Parallel RGB (1 ch, 8-bit) , 53 pins FPC |
| energia hornidura | 1.8/5.0/-5.0/14.5/-14.5V (Typ.)(VSHD/VSHA/GVSS/VGH/VGL) |
| ingurunea | Operating Temperature: 0 ~ 40 °C ; Storage Temperature: -25 ~ 60 °C |
