| PartZenbakia | LQ038B7DB01 |
| Marka | SHARP |
| Tamaina | 3.8 |
| Aplikazio | HHP |
| Ebazpena | 320×480 |
| Konposizioa | LCM |
| Distira | |
| CR | 60:1 |
| Koloreak | 262K |
| Atzeko argia | No B/L |
| Interfazea | TTL |
| panel marka | SHARP |
| panel eredua | LQ038B7DB01 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 3.8 inch |
| ebazpena | 320(RGB)×480 , HVGA |
| bistaratzeko modua | TN, Normally White, Transflective |
| eremu aktiboa | 52.8×79.2 mm |
| eskema | 64.9×92.3 mm |
| azalera | Clear, Hard coating |
| distira | |
| kontraste-erlazioa | 60:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| bistaratzeko koloreak | 262K (6-bit) |
| erantzun denbora | 20/35 (Typ.)(Tr/Td) |
| ikuspegi angelua | 40/40/40/50 (Typ.)(CR≥2)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | No B/L |
| seinale interfazea | Parallel RGB (1 ch, 6-bit), 39 pins |
| sarrerako tentsioa | 4.8/3.3/13.0/-10.0V (Typ.)(VSHA/VSHD/VDD/VEE) |
| aplikazio | HHP |
