| PartZenbakia | LP116WH1-TLP1 |
| Marka | LG Display |
| Tamaina | 11.6 |
| Aplikazio | NOPC |
| Ebazpena | 1366×768 |
| Konposizioa | LCM |
| Distira | 200 |
| CR | 300:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | LG Display |
| panel eredua | LP116WH1-TLP1 5 Compatible model |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 11.6 inch |
| ebazpena | 1366(RGB)×768 , WXGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 256.125×144 mm |
| eskema | 268×161.5×5.2 mm |
| forma estiloa | Wedge (PCBA Bent, Depth ≥5.2mm) |
| azalera | Antiglare |
| distira | 200 cd/m² (Typ.) |
| kontraste-erlazioa | 300:1 (Min.) |
| bistaratzeko koloreak | 262K (6-bit) |
| erantzun denbora | 16 (Typ.)(Tr+Td) |
| ikuspegi angelua | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | WLEDEmbedded (LED Driver) |
| seinale interfazea | LVDS (1 ch, 6-bit), 40 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | NOPC |
| LP116WF1-SPA1 | LG Display | 11.6 | 1920×1080 |
| LP116WH1-TLA1 | LG Display | 11.6 | 1366×768 |
| LP116WH1-TLN1 | LG Display | 11.6 | 1366×768 |
| LP116WH1-TLP1 | LG Display | 11.6 | 1366×768 |
| LP116WH4-SLA1 | LG Display | 11.6 | 1366×768 |
| LP116WH4-SLN1 | LG Display | 11.6 | 1366×768 |
| LP116WH4-SLN2 | LG Display | 11.6 | 1366×768 |
| LP116WH4-TJA3 | LG Display | 11.6 | 1366×768 |
| LP116WH6-SLA1 | LG Display | 11.6 | 1366×768 |
| LP116WH6-SPA2 | LG Display | 11.6 | 1366×768 |
| AT102TN42 | Innolux | 10.2 | 1024×600 |
| B101AW06 V1 HW1A | AUO | 10.1 | 1024×600 |
| B116XTN01.0 HW1A | AUO | 11.6 | 1366×768 |
| B116XW05 V0 | AUO | 11.6 | 1366×768 |
| HSD100IFW4-A00 | HannStar | 10.1 | 1024×600 |
| HT089WX1-100 | HYDIS | 8.9 | 1280×768 |
| LTN101NT06-W03 | Samsung | 10.1 | 1024×600 |
| N089A1-L01 | Innolux | 8.9 | 1280×768 |
| N089L6-L02 | Innolux | 8.9 | 1024×600 |
| N116B6-L02 | Innolux | 11.6 | 1366×768 |
