| PartZenbakia | LMS480KC02 |
| Marka | Samsung |
| Tamaina | 4.8 |
| Aplikazio | PND |
| Ebazpena | 800×480 |
| Konposizioa | LCM |
| Distira | 400 |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | SAMSUNG |
| panel eredua | LMS480KC02 |
| panel mota | LTPS TFT-LCD , LCM |
| panelaren tamaina | 4.8 inch |
| ebazpena | 800(RGB)×480 , WVGA |
| bistaratzeko modua | Normally Black, Transmissive |
| eremu aktiboa | 104.4×62.64 mm |
| eskema | 112×75 mm |
| azalera | |
| distira | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193150% |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 6S2PWLEDWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 8-bit) + SPI, 50 pins |
| sarrerako tentsioa | 3.3/3.3V (Typ.)(VCC/VCCIO) |
| aplikazio | PND |
| 35QVW1H | SII | 3.5 | 320×240 |
| A040FL01 V2 | AUO | 4.0 | 480×272 |
| AM480272H3TMQW-T00H | AMPIRE | 4.3 | 480×272 |
| AT043TN24 V.7 | Innolux | 4.3 | 480×272 |
| LB050WQ2-TD03 | LG Display | 5.0 | 480×272 |
| LMS480KC02 | Samsung | 4.8 | 800×480 |
| LMS500HF13-002 | Samsung | 5.0 | 480×272 |
| LMS500HF13-003 | Samsung | 5.0 | 480×272 |
| LR043JC111 | Innolux | 4.3 | 480×272 |
| PA050XS1 | E Ink | 5.0 | 320×234 |
