| PartZenbakia | LM140GF1L02 |
| Marka | PANDA |
| Tamaina | 14.0 |
| Aplikazio | Laptop |
| Ebazpena | 2560×1600 |
| Konposizioa | LCM , Oxide TFT-LC |
| Distira | |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | eDP |
| fabrikatzailea | PANDA |
| pantailaren tamaina | 14.0 inch |
| pixel-zenbakia | 2560(RGB)×1600 (WQXGA) 215PPI |
| eremu aktiboa (mm) | 301.824 × 188.64 (H×V) |
| bezela eremua (mm) | - |
| luminantzia | 300 cd/m² (Typ.) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10) |
| ikuspegi ona | Symmetry |
| kolore-sakonera | 16.7M 71% NTSC |
| eskema forma | Slim (PCBA Flat, T≤3.2mm) |
| freskatze tasa | 60Hz |
| seinale mota | eDP (2 Lanes) , eDP1.4 , HBR2 (5.4G/lane) , 30 pins Connector |
| tentsio-hornidura | 3.3V (Typ.) |
| gehienez. balorazioak | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| ereduaren izena | LM140GF1L02 (NCP006A) 1 Compatible |
| pantaila mota | LCM , Oxide TFT-LCD |
| antolamendua | RGB Vertical Stripe |
| eskema (mm) | 306.824 × 205.84 × 2.4 (H×V×D) |
| tratamendua | Antiglare (Haze 25%) |
| kontraste-erlazioa | 1000 : 1 (Typ.) (TM) |
| erantzuna | 25 (Typ.)(Tr+Td) ms |
| lan egiteko modua | FFS, Normally Black, Transmissive |
| atzeko argia | WLED , 15K hours , With LED Driver |
| erabiltzen | Laptop |
| pantaila taktila | Without |
