| PartZenbakia | LA123WF4-SR09 |
| Marka | LG Display |
| Tamaina | 12.3 |
| Aplikazio | Automotive Display |
| Ebazpena | 1920×720 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | 8S6P |
| Interfazea | RSDS |
| panel marka | LG Display |
| panel eredua | LA123WF4-SR09 |
| panelaren tamaina | 12.3" |
| panel mota | a-Si TFT-LCD, LCM |
| ebazpena | 1920(RGB)×720, 167PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 292.032(W)×109.512(H) mm |
| bezela irekidura | 296.03(W)×113.5(H) mm |
| eskema tamaina | 310(W)×128(H) ×10.75(D) mm |
| azalera | Antiglare, Antireflection |
| distira | 600 cd/m² (Min.) |
| kontraste-erlazioa | 800:1 (Min.) (TM) |
| ikuspegi angelua | 89/89/89/89 (Min.)(CR≥10) |
| bistaratzeko modua | IPS, Normally Black, Transmissive |
| ikuspegirik onena | Symmetry |
| erantzun denbora | 30 (Max.)(G to G); 30 (Typ.)(MPRT) |
| bistaratzeko koloreak | 16.7M 77% NTSC |
| lanpara mota | 8S6P WLED , 10K hours , Without Driver |
| maiztasuna | 60Hz |
| pantaila taktila | Without |
| panelaren pisua | - |
| aplikazio | Automotive Display |
| seinale interfazea | RSDS (2 Channel) , 110 pins FPC |
| sarrerako tentsioa | 3.3/13.0V (Typ.)(VCC/VDD) |
| ingurunea | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
