| PartZenbakia | LA123WF4-SR03 |
| Marka | LG Display |
| Tamaina | 12.3 |
| Aplikazio | Automotive Display |
| Ebazpena | 1920×720 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | RSDS |
| marka | LG Display |
| eredua | LA123WF4-SR03 |
| diagonalaren tamaina | 12.3 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 1920(RGB)×720 167PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 292.032(H)×109.512(V) mm |
| eskema dim. | 310(H)×128(V) ×10.75(D) mm |
| bezela eremua | 296.03(H)×113.5(V) mm |
| tratamendua | Hard coating |
| luminantzia | 600 cd/m² (Min.) |
| kontraste-erlazioa | 800:1 (Min.) (TM) |
| ikusi norabidea | Symmetry |
| erantzun denbora | 30 (Max.)(G to G); 25 (Typ.)(MPRT) |
| ikuspegi angelua | 89/89/89/89 (Min.)(CR≥10) |
| funtzionamendu modua | IPS, Normally Black, Transmissive |
| euskarria kolorea | 16.7M 77% NTSC |
| argi iturria | WLED [11S4P] , 10K hours , W/O Driver |
| pisua | 385/400g (Typ./Max.) |
| entzat diseinatua | Automotive Display |
| fotograma-tasa | 60Hz |
| ukipen-panela | Without |
| interfaze mota | RSDS (2 Channel) , 110 pins FPC |
| energia hornidura | 3.3/13.0V (Typ.)(VCC/VDD) |
| ingurunea | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
