| PartZenbakia | KCG057QV1DB-G500 |
| Marka | Kyocera |
| Tamaina | 5.7 |
| Aplikazio | IA |
| Ebazpena | 320×240 |
| Konposizioa | LCM |
| Distira | 400 |
| CR | 55:1 |
| Koloreak | Color |
| Atzeko argia | CCFL |
| Interfazea | Parallel Data |
| panel marka | Kyocera |
| panel eredua | KCG057QV1DB-G500 |
| panel mota | CSTN-LCD , LCM |
| panelaren tamaina | 5.7 inch |
| ebazpena | 320(RGB)×240 , QVGA |
| bistaratzeko modua | STN, Normally Black, Transmissive |
| eremu aktiboa | 115.2×86.4 mm |
| eskema | 144×104.8×13.2 mm |
| azalera | Glare (Haze 0%) |
| distira | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 55:1 (Typ.) |
| bistaratzeko koloreak | Color |
| erantzun denbora | 180/170 (Typ.)(Tr/Td) |
| ikuspegi angelua | 50/50/20/35 (Typ.)(CR≥2)(L/R/U/D) |
| maiztasuna | 75Hz |
| lanpara mota | 1 pcsCCFLOptional |
| seinale interfazea | Parallel Data (8-bit), 20 pins |
| sarrerako tentsioa | 3.3/5.0V (Typ.)(VDD) |
| aplikazio | IA |
