| PartZenbakia | JJ103IA-12A |
| Marka | Innolux |
| Tamaina | 10.3 |
| Aplikazio | Outdoor High Brightn |
| Ebazpena | 1920×720 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 1300:1 |
| Koloreak | 16.7M |
| Atzeko argia | 4 |
| Interfazea | LVDS |
| panel marka | Innolux |
| panelaren tamaina | 10.3" |
| ebazpena | 1920(RGB)×720, 200PPI |
| bistaratzeko eremua | 243.648(W)×91.368(H) mm |
| eskema tamaina | 255.24(W)×106.68(H) mm |
| distira | 800 cd/m² (Typ.) |
| ikuspegi angelua | 80/80/80/80 (Min.)(CR≥10) |
| ikuspegirik onena | Symmetry |
| bistaratzeko koloreak | 16.7M 71% NTSC |
| maiztasuna | 60Hz |
| panelaren pisua | 380g (Max.) |
| seinale interfazea | LVDS (2 ch, 8-bit) , 50 pins Connector |
| sarrerako tentsioa | 3.3V (Typ.) |
| ingurunea | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| panel eredua | JJ103IA-12A |
| panel mota | a-Si TFT-LCD , LCM |
| pixel formatua | RGB Vertical Stripe |
| bezela irekidura | 246.65(W)×94.37(H) mm |
| azalera | Antiglare |
| kontraste-erlazioa | 1300:1 (Typ.) (TM) |
| bistaratzeko modua | IPS, Normally Black, Transmissive |
| erantzun denbora | 27 (Typ.)(Tr+Td) |
| lanpara mota | 4 strings WLED , 10K hours , Without Driver |
| pantaila taktila | Without |
| aplikazio | Outdoor High Brightness Automotive Display |
