| PartZenbakia | HV750QUB-F90 |
| Marka | BOE |
| Tamaina | 75 |
| Aplikazio | TV Sets |
| Ebazpena | 3840×2160 |
| Konposizioa | a-Si TFT-LCD, CELL |
| Distira | |
| CR | 1200:1 |
| Koloreak | 1.07B |
| Atzeko argia | No |
| Interfazea | V-by-One |
| panel marka | BOE |
| panel eredua | HV750QUB-F90 |
| panelaren tamaina | 75" |
| panel mota | a-Si TFT-LCD, CELL |
| ebazpena | 3840(RGB)×2160, UHD, 59PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 1649.66(W)×927.936(H) mm |
| bezela irekidura | - |
| eskema tamaina | 1661.66(W)×942.44(H) ×1.32(D) mm |
| azalera | Antiglare (Haze 1%), Hard coating (3H) |
| distira | 0 cd/m² |
| kontraste-erlazioa | 1200:1 (Typ.) (TM) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10) |
| bistaratzeko modua | ADS, Normally Black, Transmissive |
| ikuspegirik onena | Symmetry |
| erantzun denbora | 8 (Typ.)(G to G) |
| beiraren sakonera | 0.50+0.50 mm |
| transmisibitatea | 5.5% (Typ.)(with Polarizer) |
| bistaratzeko koloreak | 1.07B 90% DCI-P3 |
| lanpara mota | No B/L |
| maiztasuna | 60Hz |
| pantaila taktila | Without |
| gidariaren ic | COF Built-in 12 source chips |
| panelaren pisua | 4.85Kgs (Typ.) |
| aplikazio | TV Sets |
| seinale interfazea | V-by-One 8 lane , 51 pins Connector |
| sarrerako tentsioa | 12.0V (Typ.) |
| ingurunea | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| LTA750FF01 | Samsung | 75 | 3840×2160 |
| LTA750FJ01 | Samsung | 75 | 3840×2160 |
| LTA750HQ01 | Samsung | 75 | 1920×1080 |
| LTI750HF01 | Samsung | 75 | 1920×1080 |
| T750QVF01.0 | AUO | 75 | 3840×2160 |
| V750DK1-KS5 Rev.F8 | Innolux | 75 | 3840×2160 |
