| PartZenbakia | HV320FHB-N80 |
| Marka | BOE |
| Tamaina | 32.0 |
| Aplikazio | TV Sets |
| Ebazpena | 1920×1080 |
| Konposizioa | a-Si TFT-LCD , CELL |
| Distira | |
| CR | 1200:1 |
| Koloreak | 16.7M |
| Atzeko argia | No |
| Interfazea | LVDS |
| panel marka | BOE |
| panelaren tamaina | 32.0" |
| ebazpena | 1920(RGB)×1080, FHD, 69PPI |
| bistaratzeko eremua | 698.4(W)×392.85(H) mm |
| eskema tamaina | 708.4(W)×405.4(H) ×1.36(D) mm |
| distira | 0 cd/m² |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10) |
| ikuspegirik onena | Symmetry |
| beiraren sakonera | 0.50+0.50 mm |
| bistaratzeko koloreak | 16.7M 98% sRGB |
| maiztasuna | 60Hz |
| gidariaren ic | COF Built-in 6 source chips |
| panelaren pisua | 850g (Typ.) |
| seinale interfazea | LVDS (2 ch, 8-bit) , 51 pins Connector |
| sarrerako tentsioa | 12.0V (Typ.) |
| ingurunea | Operating Temp.: 0 ~ 60 °C ; Storage Temp.: -20 ~ 60 °C |
| panel eredua | HV320FHB-N80 |
| panel mota | a-Si TFT-LCD , CELL |
| pixel formatua | RGB Vertical Stripe |
| bezela irekidura | - |
| azalera | Antiglare (Haze 1%), Hard coating (3H) |
| kontraste-erlazioa | 1200:1 (Typ.) (TM) |
| bistaratzeko modua | ADSDS, Normally Black, Transmissive |
| erantzun denbora | 8 (Typ.)(G to G) |
| transmisibitatea | 5.0% (Typ.)(with Polarizer) |
| lanpara mota | No B/L |
| pantaila taktila | Without |
| aplikazio | TV Sets |
| BRS-320H02 | 32.0 | 1920×1080 | |
| HV320FHB-N00 | BOE | 31.5 | 1920×1080 |
| HV320FHB-N10 | BOE | 31.5 | 1920×1080 |
| M320QAN01.0 | AUO | 32.0 | 3840×2160 |
| V320B1-L01 | Innolux | 32.0 | 1366×768 |
| V320B1-L06 | Innolux | 32.0 | 1366×768 |
