| PartZenbakia | HSD173PUW1-A01 |
| Marka | HannStar |
| Tamaina | 17.3 |
| Aplikazio | NBPC |
| Ebazpena | 1920×1080 |
| Konposizioa | LCM |
| Distira | 220 |
| CR | 500:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | HannStar |
| panel eredua | HSD173PUW1-A01 2 Compatible model |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 17.3 inch |
| ebazpena | 1920(RGB)×1080 , FHD |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 381.888×214.812 mm |
| eskema | 398.1×232.8×5.8 mm |
| forma estiloa | Wedge (PCBA Bent, Depth ≥5.2mm) |
| azalera | Glare (Haze 0%), Hard coating (3H) |
| distira | 220 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit) |
| erantzun denbora | 2.4/5.6 (Typ.))(Tr/Td) |
| ikuspegi angelua | 80/80/60/75 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | WLEDEmbedded (LED Driver) |
| seinale interfazea | LVDS (2 ch, 6-bit), 40 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | NBPC |
