| PartZenbakia | HSD156JUW2-A13 |
| Marka | HannStar |
| Tamaina | 15.6 |
| Aplikazio | Outdoor High Brightn |
| Ebazpena | 1920×1080 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | 4 |
| Interfazea | LVDS |
| panel marka | HannStar |
| panelaren tamaina | 15.6" |
| ebazpena | 1920(RGB)×1080, FHD, 141PPI |
| bistaratzeko eremua | 344.16(W)×193.59(H) mm |
| eskema tamaina | 363.7(W)×215.7(H) mm |
| distira | 850 cd/m² (Typ.) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| ikuspegirik onena | Symmetry |
| bistaratzeko koloreak | 16.7M 70% |
| maiztasuna | 60Hz |
| panelaren pisua | TBD |
| seinale interfazea | LVDS (2 ch, 8-bit) , 50 pins Connector |
| sarrerako tentsioa | 5.0V (Typ.) |
| ingurunea | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| panel eredua | HSD156JUW2-A13 |
| panel mota | a-Si TFT-LCD , LCM |
| pixel formatua | RGB Vertical Stripe |
| bezela irekidura | - |
| azalera | Hard coating |
| kontraste-erlazioa | 1000:1 (Typ.) (TM) |
| bistaratzeko modua | IPS Pro, Normally Black, Transmissive |
| erantzun denbora | 15/15 (Max.)(Tr+Td) |
| lanpara mota | 4 strings WLED , 30K hours , Without Driver |
| pantaila taktila | Without |
| aplikazio | Outdoor High Brightness Automotive Display |
