| PartZenbakia | HSD123KPW2-A10 |
| Marka | HannStar |
| Tamaina | 12.3 |
| Aplikazio | Automotive Display |
| Ebazpena | 1920×720 |
| Konposizioa | LCM , a-Si TFT-LCD |
| Distira | |
| CR | 1100:1 |
| Koloreak | 16.7M |
| Atzeko argia | 11S4P |
| Interfazea | LVDS |
| fabrikatzailea | HannStar |
| pantailaren tamaina | 12.3 inch |
| pixel-zenbakia | 1920(RGB)×720 167PPI |
| eremu aktiboa (mm) | 292.032 × 109.512 (H×V) |
| bezela eremua (mm) | 294.8 × 112.1 (H×V) |
| luminantzia | 850 cd/m² (Typ.) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| ikuspegi ona | Symmetry |
| kolore-sakonera | 16.7M 70% NTSC |
| masa | TBD |
| freskatze tasa | 60Hz |
| seinale mota | LVDS (2 ch, 8-bit) , 50 pins Connector |
| tentsio-hornidura | 3.3V (Typ.) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| ereduaren izena | HSD123KPW2-A10 |
| pantaila mota | LCM , a-Si TFT-LCD |
| antolamendua | RGB Vertical Stripe |
| eskema (mm) | 308.1 × 130 × 15.6 (H×V×D) |
| tratamendua | Glare (Haze 0%) |
| kontraste-erlazioa | 1100 : 1 (Typ.) (TM) |
| erantzuna | 16/14 (Typ.)(Tr/Td) ms |
| lan egiteko modua | IPS Pro, Normally Black, Transmissive |
| atzeko argia | 11S4P WLED , 30K hours , No Driver |
| erabiltzen | Automotive Display |
| pantaila taktila | Without |
