| PartZenbakia | HSD123JPW1-A20 |
| Marka | HannStar |
| Tamaina | 12.3 |
| Aplikazio | Outdoor High Brightn |
| Ebazpena | 1920×720 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | 11S4P |
| Interfazea | LVDS |
| panel marka | HannStar |
| panel eredua | HSD123JPW1-A20 |
| panelaren tamaina | 12.3" |
| panel mota | a-Si TFT-LCD, LCM |
| ebazpena | 1920(RGB)×720, 167PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 292.032(W)×109.512(H) mm |
| bezela irekidura | 294.8(W)×112.1(H) mm |
| eskema tamaina | 308.1(W)×130(H) ×16.6(D) mm |
| azalera | Antiglare |
| distira | 850 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) (TM) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| bistaratzeko modua | IPS Pro, Normally Black, Transmissive |
| ikuspegirik onena | Symmetry |
| erantzun denbora | 18/17 (Typ.)(Tr/Td) |
| bistaratzeko koloreak | 16.7M 70% NTSC |
| lanpara mota | 11S4P WLED , 30K hours , Without Driver |
| maiztasuna | 60Hz |
| pantaila taktila | Without |
| panelaren pisua | 520g (Typ.) |
| aplikazio | Outdoor High Brightness Automotive Display |
| seinale interfazea | LVDS (2 ch, 8-bit) , 50 pins Connector |
| sarrerako tentsioa | 3.3V (Typ.) |
| ingurunea | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
