| PartZenbakia | HSD103JPW2-H10 |
| Marka | HannStar |
| Tamaina | 10.3 |
| Aplikazio | Outdoor High Brightn |
| Ebazpena | 1920×720 |
| Konposizioa | LCM , a-Si TFT-LCD |
| Distira | |
| CR | 1500:1 |
| Koloreak | 16.7M |
| Atzeko argia | 4 |
| Interfazea | LVDS |
| fabrikatzailea | HannStar |
| pantailaren tamaina | 10.3 inch |
| pixel-zenbakia | 1920(RGB)×720 200PPI |
| eremu aktiboa (mm) | 243.648 × 91.368 (H×V) |
| bezela eremua (mm) | 246.7 × 94.4 (H×V) |
| luminantzia | 1000 cd/m² (Typ.) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| ikuspegi ona | Symmetry |
| kolore-sakonera | 16.7M 70% NTSC |
| masa | TBD |
| freskatze tasa | 60Hz |
| seinale mota | LVDS (2 ch, 8-bit) , 60 pins FPC |
| tentsio-hornidura | 3.3V (Typ.) |
| gehienez. balorazioak | Storage Temp.: -40 ~ 95 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| ereduaren izena | HSD103JPW2-H10 |
| pantaila mota | LCM , a-Si TFT-LCD |
| antolamendua | RGB Vertical Stripe |
| eskema (mm) | 258.8 × 110 × 17 (H×V×D) |
| tratamendua | Antiglare, Hard coating (3H) |
| kontraste-erlazioa | 1500 : 1 (Typ.) (TM) |
| erantzuna | 30 (Max.)(Tr+Td) ms |
| lan egiteko modua | IPS Pro, Normally Black, Transmissive |
| atzeko argia | 4 strings WLED , 20K hours , No Driver |
| erabiltzen | Outdoor High Brightness Automotive Display |
| pantaila taktila | Without |
