| PartZenbakia | HSD103JPW2-A00 |
| Marka | HannStar |
| Tamaina | 10.3 |
| Aplikazio | Outdoor High Brightn |
| Ebazpena | 1920×720 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | |
| marka | HannStar |
| eredua | HSD103JPW2-A00 |
| diagonalaren tamaina | 10.3 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 1920(RGB)×720 200PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 243.648(H)×91.368(V) mm |
| eskema dim. | 259.8(H)×112(V) ×15.7(D) mm |
| bezela eremua | 246.05(H)×93.77(V) mm |
| tratamendua | Antiglare, Hard coating (3H) |
| luminantzia | 850 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) (TM) |
| ikusi norabidea | Symmetry |
| erantzun denbora | 35 (Max.)(Tr+Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| funtzionamendu modua | IPS Pro, Normally Black, Transmissive |
| euskarria kolorea | 16.7M 70% NTSC |
| argi iturria | WLED [9S4P] , 20K hours , W/O Driver |
| pisua | TBD |
| entzat diseinatua | Outdoor High Brightness Automotive Display |
| fotograma-tasa | 60Hz |
| ukipen-panela | Without |
| Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
