| PartZenbakia | HSD101JFW1-C11 |
| Marka | HannStar |
| Tamaina | 10.1 |
| Aplikazio | Automotive Display |
| Ebazpena | 1024×600 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 800:1 |
| Koloreak | 16.2M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| marka | HannStar |
| eredua | HSD101JFW1-C11 |
| diagonalaren tamaina | 10.1 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 1024(RGB)×600 [WSVGA] 117PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 222.72(H)×125.28(V) mm |
| eskema dim. | 235(H)×143(V) ×6.3(D) mm |
| bezela eremua | 226(H)×128.5(V) mm |
| tratamendua | Hard coating (3H) |
| luminantzia | 500 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) (TM) |
| ikusi norabidea | Symmetry |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| funtzionamendu modua | IPS Pro, Normally Black, Transflective |
| euskarria kolorea | 16.2M 45% NTSC |
| argi iturria | WLED [6S7P] , 20K hours , W/O Driver |
| pisua | 265/275g (Typ./Max.) |
| entzat diseinatua | Automotive Display |
| fotograma-tasa | 60Hz |
| ukipen-panela | Without |
| interfaze mota | LVDS (1 ch, 8-bit) , 60 pins FPC |
| energia hornidura | 3.3/12.5/20/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| ingurunea | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
