| PartZenbakia | HSD090JFW1-A02 |
| Marka | HannStar |
| Tamaina | 9.0 |
| Aplikazio | Automotive Display |
| Ebazpena | 1024×600 |
| Konposizioa | LCM, a-Si TFT-LCD |
| Distira | |
| CR | 800:1 |
| Koloreak | 16.2M |
| Atzeko argia | 3S13P |
| Interfazea | LVDS |
| fabrikatzailea | HannStar |
| ereduaren izena | HSD090JFW1-A02 |
| pantailaren tamaina | 9.0 inch |
| pantaila mota | LCM, a-Si TFT-LCD |
| pixel-zenbakia | 1024(RGB)×600 (WSVGA) 132PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 196.608 × 114.15 (H×V) |
| eskema (mm) | 211.1 × 126.5 × 6 (H×V×D) |
| bezela eremua (mm) | 200.01 × 117.55 (H×V) |
| tratamendua | Antiglare, Hard coating (3H) |
| luminantzia | 500 cd/m² (Typ.) |
| kontraste-erlazioa | 800 : 1 (Typ.) (TM) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| erantzuna | 17/18 (Typ.)(Tr/Td) ms |
| ikuspegi ona | Symmetry |
| lan egiteko modua | IPS Pro, Normally Black, Transmissive |
| kolore-sakonera | 16.2M 50% NTSC |
| atzeko argia | 3S13P WLED , 15K hours , No Driver |
| masa | 226g (Typ.) |
| erabiltzen | Automotive Display |
| freskatze tasa | 60Hz |
| pantaila taktila | Without |
| seinale mota | LVDS (1 ch, 8-bit) , FPC 40 pins |
| tentsio-hornidura | 3.3/12.5/23/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.9G (28.4 m/s²) |
