| PartZenbakia | HSD089IFW3-A00 |
| Marka | HannStar |
| Tamaina | 8.9 |
| Aplikazio | |
| Ebazpena | 1024×600 |
| Konposizioa | LCM |
| Distira | 200 |
| CR | 500:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | HannStar |
| panel eredua | HSD089IFW3-A00 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 8.9 inch |
| ebazpena | 1024(RGB)×600 , WSVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 195.072×113.4 mm |
| eskema | 213.66×129.85 mm |
| azalera | |
| distira | 200 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193150% |
| erantzun denbora | 12 (Typ.)(Tr+Td) |
| ikuspegi angelua | 75/75/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| lanpara mota | WLED |
| seinale interfazea | LVDS (1 ch, 6-bit), 40 pins |
| rohs: |
