| PartZenbakia | GV185FHM-N10-DM30 |
| Marka | BOE |
| Tamaina | 18.5 |
| Aplikazio | Industrial |
| Ebazpena | 1920×1080 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | 11S4P |
| Interfazea | LVDS |
| panel marka | BOE |
| panel eredua | GV185FHM-N10-DM30 |
| panelaren tamaina | 18.5" |
| panel mota | a-Si TFT-LCD, LCM |
| ebazpena | 1920(RGB)×1080, FHD, 119PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 408.96(W)×230.04(H) mm |
| bezela irekidura | 410.96(W)×232.04(H) mm |
| eskema tamaina | 430.4(W)×254.6(H) ×12.5(D) mm |
| azalera | Antiglare (Haze 25%), Hard coating (3H) |
| distira | 350 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) (TM) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| bistaratzeko modua | ADS, Normally Black, Transmissive |
| ikuspegirik onena | Symmetry |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| bistaratzeko koloreak | 16.7M 70% NTSC |
| lanpara mota | 11S4P WLED , With LED Driver |
| maiztasuna | 60Hz |
| pantaila taktila | Without |
| panelaren pisua | 1.80Kgs (Typ.) |
| aplikazio | Industrial |
| seinale interfazea | LVDS (2 ch, 8-bit) , 30 pins Connector |
| sarrerako tentsioa | 5.0V (Typ.) |
| ingurunea | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| LM185TT1A | PANDA | 18.5 | 1366×768 |
| LM185TT2A | PANDA | 18.5 | 1366×768 |
| LM185WH2-TLD1 | LG Display | 18.5 | 1366×768 |
| M185B1-L07 | Innolux | 18.5 | 1366×768 |
| M185BGE-L22 | Innolux | 18.5 | 1366×768 |
| M185XTN01.3 | AUO | 18.5 | 1366×768 |
| M185XW01 V2 | AUO | 18.5 | 1366×768 |
| M185XW01 V5 | AUO | 18.5 | 1366×768 |
| M185XW01 V6 | AUO | 18.5 | 1366×768 |
| MT185GW01 V.0 | Innolux | 18.5 | 1366×768 |
