| PartZenbakia | G185XW01 V201 |
| Marka | AUO |
| Tamaina | 18.5 |
| Aplikazio | Industrial |
| Ebazpena | 1366×768 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | AUO |
| panel eredua | G185XW01 V201 |
| panelaren tamaina | 18.5" |
| panel mota | a-Si TFT-LCD, LCM |
| ebazpena | 1366(RGB)×768, WXGA, 84PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 409.8(W)×230.4(H) mm |
| bezela irekidura | 413.4(W)×234.0(H) mm |
| eskema tamaina | 430.4(W)×254.7(H) mm |
| azalera | Antiglare, Hard coating (3H) |
| distira | 450 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) (TM) |
| ikuspegi angelua | 85/85/80/80 (Typ.)(CR≥10) |
| bistaratzeko modua | TN, Normally White, Transmissive |
| ikuspegirik onena | - |
| erantzun denbora | 3.5/1.5 (Typ.)(Tr/Td) |
| bistaratzeko koloreak | 16.7M 70% NTSC |
| lanpara mota | WLED , 50K hours , With LED Driver |
| maiztasuna | 60Hz |
| pantaila taktila | Without |
| panelaren pisua | 1.44Kgs (Max.) |
| aplikazio | Industrial |
| seinale interfazea | LVDS (1 ch, 8-bit) , 30 pins Connector |
| sarrerako tentsioa | 5.0V (Typ.) |
| ingurunea | Operating Temp.: 0 ~ 60 °C ; Storage Temp.: -20 ~ 60 °C |
