| PartZenbakia | G150XTN03.8 |
| Marka | AUO |
| Tamaina | 15.0 |
| Aplikazio | Industrial |
| Ebazpena | 1024×768 |
| Konposizioa | LCM , a-Si TFT-LCD |
| Distira | |
| CR | 800:1 |
| Koloreak | 262K/16.2M |
| Atzeko argia | WLED |
| Interfazea | eDP |
| fabrikatzailea | AUO |
| pantailaren tamaina | 15.0 inch |
| pixel-zenbakia | 1024(RGB)×768 (XGA) 85PPI |
| eremu aktiboa (mm) | 304.128 × 228.096 (H×V) |
| bezela eremua (mm) | 312.55 × 236.25 (H×V) |
| luminantzia | 400 cd/m² (Typ.) |
| ikuspegi angelua | 80/80/70/80 (Typ.)(CR≥10) |
| ikuspegi ona | - |
| kolore-sakonera | 262K/16.2M 60% NTSC |
| masa | 720g (Max.) |
| freskatze tasa | 60Hz |
| seinale mota | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| tentsio-hornidura | 3.3V (Typ.) |
| gehienez. balorazioak | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 60 °C |
| ereduaren izena | G150XTN03.8 |
| pantaila mota | LCM , a-Si TFT-LCD |
| antolamendua | RGB Vertical Stripe |
| eskema (mm) | 326.5 × 253.5 × 6.8 (H×V×D) |
| tratamendua | Antiglare, Hard coating (3H) |
| kontraste-erlazioa | 800 : 1 (Typ.) (TM) |
| erantzuna | 5.7/3.2 (Typ.)(Tr/Td) ms |
| lan egiteko modua | TN, Normally White, Transmissive |
| atzeko argia | WLED , 50K hours , With LED Driver |
| erabiltzen | Industrial |
| pantaila taktila | Without |
