| PartZenbakia | G104XVN01.1 |
| Marka | AUO |
| Tamaina | 10.4 |
| Aplikazio | Industrial |
| Ebazpena | 1024×768 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 3000:1 |
| Koloreak | 262K/16.2M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | AUO |
| panel eredua | G104XVN01.1 |
| panelaren tamaina | 10.4" |
| panel mota | a-Si TFT-LCD, LCM |
| ebazpena | 1024(RGB)×768, XGA, 123PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 210.4(W)×157.8(H) mm |
| bezela irekidura | 215.4(W)×161.8(H) mm |
| eskema tamaina | 238.6(W)×175.8(H) ×7(D) mm |
| azalera | Antiglare, Hard coating (3H) |
| distira | - |
| kontraste-erlazioa | 3000:1 (Typ.) (TM) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10) |
| bistaratzeko modua | AMVA3, Normally Black, Transmissive |
| ikuspegirik onena | Symmetry |
| erantzun denbora | 20/10 (Typ.)(Tr/Td) |
| bistaratzeko koloreak | 262K/16.2M |
| lanpara mota | WLED , With LED Driver |
| maiztasuna | 60Hz |
| pantaila taktila | Without |
| panelaren pisua | - |
| aplikazio | Industrial |
| seinale interfazea | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| sarrerako tentsioa | 3.3V (Typ.) |
| G104X1-L01 | Innolux | 10.4 | 1024×768 |
| G104X1-L02 | Innolux | 10.4 | 1024×768 |
| G104X1-L03 | Innolux | 10.4 | 1024×768 |
| G104X1-L04 | Innolux | 10.4 | 1024×768 |
| G104XGE-L05 | Innolux | 10.4 | 1024×768 |
| G104XVN01.0 | AUO | 10.4 | 1024×768 |
| LQ104V1DC41 | SHARP | 10.4 | 640×480 |
| LQ104X2LX05B | SHARP | 10.4 | 1024×768 |
| NL6448BC33-53 | NLT | 10.4 | 640×480 |
| TM104QDSG09 | Tianma | 10.4 | 640×480 |
