| PartZenbakia | G070VAN01.0 |
| Marka | AUO |
| Tamaina | 7.0 |
| Aplikazio | Industrial |
| Ebazpena | 800×480 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 1300:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| marka | AUO |
| eredua | G070VAN01.0 |
| diagonalaren tamaina | 7.0 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 800×480(RGB) [WVGA] 133PPI |
| konfigurazioa | RGB Horizontal Stripe |
| eremu aktiboa | 152.4(H)×91.44(V) mm |
| eskema dim. | 166.6(H)×107(V) ×10(D) mm |
| bezela eremua | 154.2(H)×93.24(V) mm |
| tratamendua | Antiglare |
| luminantzia | 480 cd/m² (Typ.) |
| kontraste-erlazioa | 1300:1 (Typ.) (TM) |
| ikusi norabidea | Symmetry |
| erantzun denbora | 11/19 (Max.)(Tr/Td) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10) |
| funtzionamendu modua | AHVA, Normally Black, Transmissive |
| euskarria kolorea | 262K/16.7M 70% NTSC |
| argi iturria | WLED [7S2P] , 50K hours , W/O Driver |
| pisua | 175±10%g |
| entzat diseinatua | Industrial |
| fotograma-tasa | 60Hz |
| ukipen-panela | Without |
| interfaze mota | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| energia hornidura | 3.3V (Typ.) |
| ingurunea | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
