| PartZenbakia | EV121WXM-N12 |
| Marka | BOE |
| Tamaina | 12.1 |
| Aplikazio | Medical Imaging |
| Ebazpena | 1280×800 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 1200:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| marka | BOE |
| eredua | EV121WXM-N12 |
| diagonalaren tamaina | 12.1 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 1280(RGB)×800 [WXGA] 124PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 261.12(H)×163.2(V) mm |
| eskema dim. | 277.7(H)×180.6(V) ×9.2(D) mm |
| bezela eremua | 264.12(H)×166.2(V) mm |
| tratamendua | Antiglare (Haze 25%) |
| luminantzia | 500 cd/m² (Typ.) |
| kontraste-erlazioa | 1200:1 (Typ.) (TM) |
| ikusi norabidea | Symmetry |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| funtzionamendu modua | ADS, Normally Black, Transmissive |
| euskarria kolorea | 262K/16.7M 100% sRGB |
| argi iturria | WLED [12S4P] , 50K hours , With LED Driver |
| pisua | TBD |
| entzat diseinatua | Medical Imaging |
| fotograma-tasa | 60Hz |
| ukipen-panela | Without |
| interfaze mota | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| energia hornidura | 3.3V (Typ.) |
| ingurunea | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AA121SP01 | Mitsubishi | 12.1 | 800×600 |
| AA121TD01-DE3 | Mitsubishi | 12.1 | 1280×800 |
| B121EW07 V1 | AUO | 12.1 | 1280×800 |
| B121EW08 V0 | AUO | 12.1 | 1280×800 |
| B121EW09 V0 | AUO | 12.1 | 1280×800 |
| FLC31SVC6S-17 | Fujitsu | 12.1 | 800×600 |
| LQ121S1DG42 | SHARP | 12.1 | 800×600 |
| LQ121S1LG45 | SHARP | 12.1 | 800×600 |
| LTD121KM1K | TOSHIBA | 12.1 | 1400×1050 |
| LTM12C318S | TOSHIBA | 12.1 | 1024×768 |
