| PartZenbakia | EL160.120.39-SPI |
| Marka | Lumineq |
| Tamaina | 3.1 |
| Aplikazio | Industrial |
| Ebazpena | 160×120 |
| Konposizioa | EL, EL |
| Distira | |
| CR | 60:1 |
| Koloreak | Mono(Yellow) |
| Atzeko argia | self |
| Interfazea | SPI |
| marka | Lumineq |
| eredua | EL160.120.39-SPI |
| diagonalaren tamaina | 3.1 inch |
| mota | EL, EL |
| pixel formatua | 160×120 [QQVGA] 65PPI |
| konfigurazioa | Rectangle |
| eremu aktiboa | 62.3(H)×46.7(V) mm |
| eskema dim. | 93.6(H)×61.5(V) mm |
| luminantzia | 70 cd/m² (Typ.) |
| kontraste-erlazioa | 60:1 (Typ.) (TM) |
| ikusi norabidea | Symmetry |
| erantzun denbora | 1 (Max.) |
| ikuspegi angelua | 89/89/89/89 (Typ.) |
| funtzionamendu modua | - |
| euskarria kolorea | Mono(Yellow) |
| argi iturria | self , 50K hours |
| pisua | 65.0g |
| entzat diseinatua | Industrial |
| fotograma-tasa | 150Hz |
| ukipen-panela | Without |
| interfaze mota | SPI , 20 pins Connector |
| energia hornidura | 5.25/18V (Typ.)(VL/VH) |
| ingurunea | Operating Temperature: -50 ~ 70 °C ; Storage Temperature: -60 ~ 105 °C ; Vibration Level: 3.16G (31.0 m/s²) |
