| PartZenbakia | CLAA123PA02CW |
| Marka | CPT |
| Tamaina | 12.3 |
| Aplikazio | Industrial Outdoor H |
| Ebazpena | 1440×540 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 700:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| marka | CPT |
| eredua | CLAA123PA02CW |
| diagonalaren tamaina | 12.3 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 1440(RGB)×540 125PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 291.6(H)×109.35(V) mm |
| eskema dim. | 312.9(H)×132.2(V) ×19.2(D) mm |
| bezela eremua | 294.8(H)×112.4(V) mm |
| tratamendua | Antiglare (Haze 25%) |
| luminantzia | 800 cd/m² (Typ.) |
| kontraste-erlazioa | 700:1 (Typ.) (TM) |
| ikusi norabidea | 6 o'clock |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 60/60/50/60 (Typ.)(CR≥10) |
| funtzionamendu modua | TN, Normally White, Transmissive |
| euskarria kolorea | 16.7M 70% NTSC |
| argi iturria | WLED [8S3P] , 30K hours , W/O Driver |
| pisua | 510g (Typ.) |
| entzat diseinatua | Industrial Outdoor High Brightness Automotive Display |
| fotograma-tasa | 60Hz |
| ukipen-panela | Without |
| interfaze mota | LVDS (1 ch, 8-bit) , 30 pins Connector |
| energia hornidura | 3.3V (Typ.) |
| ingurunea | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
